ESP32 CAM Board WIFI+BLUETOOTH With OV2640 Camera Module

In Stock
EGP350.00 EGP310.00
In Stock
Category: Tags: , ,

Description

  • Features :

    • The smallest 802.11b/g/n Wi-Fi BT SoC module
    • Low power 32-bit CPU,can also serve the application processor
    • Up to 160MHz clock speed, summary computing power up to 600 DMIPS
    • Built-in 520 KB SRAM, external 4MPSRAM
    • Supports UART/SPI/I2C/PWM/ADC/DAC
    • Support OV2640 and OV7670 cameras, built-in flash lamp
    • Support image WiFI upload
    • Support TF card
    • Supports multiple sleep modes
    • Embedded Lwip and FreeRTOS
    • Supports STA/AP/STA+AP operation mode
    • Support Smart Config/AirKiss technology
    • Support for serial port local and remote firmware upgrades (FOTA)

    For Tutorial of this product click here.

    There are three GND pins and two pins for power: either 3.3V or 5V.

    GPIO 1 and GPIO 3 are the serial pins. You need these pins to upload code to your board. Additionally, GPIO 0 also plays an important role, since it determines whether the ESP32 is in flashing mode or not. When GPIO 0 is connected to GND, the ESP32 is in flashing mode.

    The following pins are internally connected to the microSD card reader:

    • GPIO 14: CLK
    • GPIO 15: CMD
    • GPIO 2: Data 0
    • GPIO 4: Data 1 (also connected to the on-board LED)
    • GPIO 12: Data 2
    • GPIO 13: Data 3
