(GY-86) 10DOF BMP085 Module MS5611 HMC5883L MPU6050 Module

Out of stock
Out of stock


GY-86 10DOF Flight Control Module Info

GY-86 10DOF Flight Control Module combines 4 sensors into a single tiny package. The board consists of an MPU6050 3-axis gyroscope and 3-axis accelerometer, an HMC5883L 3-axis magnetometer and a MS5611 barometer. All of the sensors are accessible via I2C interface.


GY-86 10DOF Flight Control Module – General Specifications

  • MPU6050 3-axis gyroscope and 3-axis accelerometer
  • HMC5883L 3-axis magnetometer
  • MS5611 barometer
  • I2C interface

GY-86 10DOF Flight Control Module – Technical Specifications

  • Supply Voltage: 3V – 5V
  • Communication Mode: I2C
  • Dimensions: 21.5 mm x 16.8 mm x 2 mm
  • Weight: 30g




HMC5883L Datasheet

MS5611 Datasheet
