Limit Switch Long Straight (50mm) 16A 125/250VAC

Out of stock
EGP15.00
Out of stock

Description

KW3-OZ KW7 long lever micro switch 3 pins 1NO 1NC 5A/10A 250VAC T85



16(6)A 250VAC green

Product Description

KW3-OZ kw7 Micro Switch 15A250V

Features:

Parameter
Rating:
1A~16A 125/250VAC
Practical temperature range:
-25 to 85 degrees Celsius
Mechanical Operating frequency
120 cycles/min
Electrical Operating frequency
25 cycles/min
Insulation resistance
≥100 MΩ(500Vdc)
Contact resistancy
≤30 mΩ(initial value)
Mechanical life
≥10,000,000cycles
Electrical life
≥500,000cycles
The above info for referrance,
welcome to contact us for detailed description of each items.
