74193 (4-bit binary up/down counter with synchronous reset )

The 74193 is a 4-bit binary up/down counter with synchronous reset and clear. It is part of the 7400 series of integrated circuits and is used in digital circuits for counting applications, typically in systems where binary counting, timing, or sequencing is needed.

74193 IC Description:

The 74193 is a 4-bit binary up/down counter, meaning it can count both up (increasing) and down (decreasing) based on a control signal. It can count from 0 to 15 (binary 0000 to 1111). The IC has asynchronous inputs for clear and load, and its counting behavior is controlled by the up/down input and the clock.

Key Features:

• 4-bit Binary Up/Down Counter: The IC can count from 0 to 15 in binary (0000 to 1111).
• Synchronous Reset: It has a reset pin (CLR) that resets the counter to 0 when activated.
• Count Control: The Up/Down (U/D) input controls whether the counter counts up or down.
• Synchronous Operation: The counter increments or decrements on the rising edge of the clock.
• Buffered Outputs: The counter’s outputs (Q0-Q3) are buffered, meaning they can drive logic-level circuits or external components directly.
• Active-low Asynchronous Clear: The clear (CLR) pin is used to reset the counter asynchronously when held low.

Pin Configuration (16-pin package):

Here's the pinout for the 74193 4-bit binary up/down counter:

1. Q0: Output bit 0 (Least Significant Bit).
2. Q1: Output bit 1.
3. Q2: Output bit 2.
4. Q3: Output bit 3 (Most Significant Bit).
5. Clock (CLK): The clock input. The counter increments or decrements on the rising edge of the clock.
6. Up/Down (U/D): This input controls the counting direction. When HIGH (1), the counter counts up; when LOW (0), it counts down.
7. Clear (CLR): Active-low asynchronous clear input. When LOW, the counter is reset to 0.
8. Load (LOAD): Active-low load input. When LOW, the data on the Data Inputs (D0-D3) is loaded into the counter.
9. D0: Data input bit 0 (Least Significant Bit).
10. D1: Data input bit 1.
11. D2: Data input bit 2.
12. D3: Data input bit 3 (Most Significant Bit).
13. Vcc: Supply voltage (typically 5V).
14. GND: Ground connection.
