BSS84 SMD (Small Signal Mosfet P-Channel) SOT-23

Description

BSS84

Type Designator: BSS84
Marking Code: SP
Type of Transistor: MOSFET
Type of Control Channel: P -Channel
Pd ⓘ – Maximum Power Dissipation: 0.36 W
|Vds|ⓘ – Maximum Drain-Source Voltage: 50 V
|Vgs|ⓘ – Maximum Gate-Source Voltage: 20 V
|Vgs(th)|ⓘ – Maximum Gate-Threshold Voltage: 2 V
|Id| ⓘ – Maximum Drain Current: 0.13 A
Tj ⓘ – Maximum Junction Temperature: 150 °C
Qg ⓘ – Total Gate Charge: 6 nC
Rds ⓘ – Maximum Drain-Source On-State Resistance: 10 Ohm
Package: SOT23

Datasheet:

https://alltransistors.com/mosfet/transistor.php?transistor=1359
