C3260 (2SC3260) Power Transistor NPN (800V , 3A)

Features :

Type Designator: 2SC3261
Material of Transistor: Si
- Polarity: NPN
- Maximum Collector Power Dissipation Pc: 50 W
- Maximum Collector-Base Voltage |Vcb|: 800 V
- Maximum Collector-Emitter Voltage |Vce|: 800 V
- Maximum Emitter-Base Voltage |Veb|: 7 V
- Maximum Collector Current |Ic max|: 3 A
- Max. Operating Junction Temperature Tj: 125 °C
- Forward Current Transfer Ratio hFE, MIN: 10
- Noise Figure, dB: -
- Package: X104
