TL064ACN (Low Power JFET Quad Operational Amplifier)

TL064ACN is a quad low-power JFET-input operational amplifier (op amp), known for its high input impedance, low input bias/offset currents, and very low power consumption. It is manufactured by companies such as Texas Instruments and STMicroelectronics.

Key Features and Specifications

• Amplifier Type: JFET-input operational amplifier.
• Channels: Contains four independent operational amplifiers on a single chip.
• Power Consumption: Very low supply current, typically 200 µA per amplifier.
• Input Impedance: High input impedance, which is characteristic of the JFET input stage.
• Slew Rate: High slew rate, typically 3.5 V/µs.
• Supply Voltage: Wide supply voltage range, typically operating with a dual supply of ±5V to ±15V, with a maximum of ±18V.
• Operating Temperature: The C-suffix indicates the commercial temperature range of 0°C to 70°C.
• Package: The N suffix denotes a 14-pin plastic dual in-line package (PDIP) for through-hole mounting.
• Features: Includes internal frequency compensation and output short-circuit protection.

Applications

The TL064ACN is suitable for a variety of cost-sensitive applications requiring low power consumption and high input impedance:

• Audio distributor amplifiers
• Tablets and personal electronics
• Computer systems
• Instrumentation circuits

Datasheet:

https://www.st.com/content/ccc/resource/technical/document/datasheet/4a/69/1f/c4/3e/0f/4f/1a/CD00000487.pdf/files/CD00000487.pdf/jcr:content/translations/en.CD00000487.pdf
