74175 (Quad D-Type Flip-Flop )

74175 IC Quad D-Type Flip-Flop

74175 IC Quad D-Type Flip-Flop with Reset Positive-Edge Trigger DIP-16

The 74175 is a Quad D-Type Flip-Flop with Reset from XBLW, designed to provide reliable storage and processing of data in sequential logic circuits. This integrated circuit features four independent D-type flip-flops, each with a reset input, allowing for greater flexibility in digital design. The flip-flops are triggered on the positive edge of the clock input, making them ideal for use in systems that require synchronized data storage and retrieval.

Features

• Four independent D-type flip-flops with reset.
• Positive-edge triggering for reliable data latching.
• Reset capability for clearing outputs to a known state.
• High-speed operation for sequential logic circuits.
• Operates over a wide voltage range for increased flexibility.
• Standard 16-pin Dual In-line Package (DIP) for easy integration.
• Commonly used in registers, counters, and memory devices.

Datasheet

• SN74LS175N
